TP-Link CPE610 IEEE 802.11a/n 300 Mbit/s Wireless Bridge

  • Part: 1104240
  • Model: CPE610
$129.17

Availability

In Stock

  • Up to 300Mbps on 5GHz wireless data rates
  • 23dBi high-gain directional 2×2 MIMO antenna and a dedicated metal reflector, ideal for long-distance application
  • Excellent beam directivity, improved latency and noise cancellation
  • Innovative snap-lock parts make for fast assembly and a sturdy structural design keeps CPE610 stable even in strong winds
  • Durable IP65 weatherproof enclosure along with 15 kV ESD and 6 kV lightning protection ensures all-weather suitability
  • TP-Link Pharos MAXtream TDMA technology improves throughput, capacity and latency performance
  • Pharos Control gives administrators a free, centralized management system
  • Passive PoE supports to allow flexible deployment and convenient installation

2×2 MIMO
MAXtream TDMA
23dBi directional antenna and professional structural stability for long-distance outdoor Wi-Fi transmission.

Professional-standard 23dBi Directional
Antenna for Long-range Wireless Transmission

With 23dBi high-gain directional 2×2 MIMO Cassegrain antenna and dedicated metal reflector, the CPE610 provides excellent beam directivity, improved latency and noise immunity. Professional performance, coupled with user-friendly design, makes the 5GHz 300Mbps 23dBi Outdoor CPE610 an ideal choice and cost effective solution for outdoor wireless networking applications.

Stable Structural Design and Flexible Installation

Snap-lock parts make assembly simple and convenient
Pole mount kits and the freedom of three-axis alignment facilitate flexible installation
Sturdy design ensures stability in windy conditions

Compact and
Lightweight Packaging

Small and lightweight boxes
benefit shipping, logistics and retail.

Pharos Control - Centralized Management System

CPE610 comes equipped with Pharos Control centralized management software, helping users easily manage all devices in their network from a single PC. Functions include device iscovery, status monitoring, firmware upgrading, and network maintenance. An intuitive web-based interface- PharOS - provides an alternative management method, and allows professionals to access more detailed configurations.

  • General Information
    • Manufacturer
    • TP-LINK Technologies Co., Ltd
    • Manufacturer Website Address
    • http://www.tp-link.com.au
    • Brand Name
    • TP-Link
    • Product Type
    • Wireless Bridge

  • Technical Information
    • Wireless LAN Standard
    • IEEE 802.11a/n
    • Frequency Band
    • 5 GHz
    • Antenna Gain (Isotropic)
    • 23 dBi
    • Wireless Transmission Speed
    • 300 Mbit/s
  • Interfaces/Ports
    • Ethernet Technology
    • Fast Ethernet
    • Number of Network (RJ-45) Ports
    • 1
    • PoE (RJ-45) Port
    • Yes
  • Power Description
    • Power Consumption
    • 8.80 W
  • Physical Characteristics
    • Height
    • 205.7 mm
    • Width
    • 365.8 mm
    • Depth
    • 279.4 mm
  • Miscellaneous
    • Environmentally Friendly
    • Yes
