- Up to 300Mbps on 5GHz wireless data rates
- 23dBi high-gain directional 2×2 MIMO antenna and a dedicated metal reflector, ideal for long-distance application
- Excellent beam directivity, improved latency and noise cancellation
- Innovative snap-lock parts make for fast assembly and a sturdy structural design keeps CPE610 stable even in strong winds
- Durable IP65 weatherproof enclosure along with 15 kV ESD and 6 kV lightning protection ensures all-weather suitability
- TP-Link Pharos MAXtream TDMA technology improves throughput, capacity and latency performance
- Pharos Control gives administrators a free, centralized management system
- Passive PoE supports to allow flexible deployment and convenient installation
2×2 MIMO
MAXtream TDMA
23dBi directional antenna and professional structural stability for long-distance outdoor Wi-Fi transmission.
Professional-standard 23dBi Directional
Antenna for Long-range Wireless Transmission
With 23dBi high-gain directional 2×2 MIMO Cassegrain antenna and dedicated metal reflector, the CPE610 provides excellent beam directivity, improved latency and noise immunity. Professional performance, coupled with user-friendly design, makes the 5GHz 300Mbps 23dBi Outdoor CPE610 an ideal choice and cost effective solution for outdoor wireless networking applications.
Stable Structural Design and Flexible Installation
Snap-lock parts make assembly simple and convenientPole mount kits and the freedom of three-axis alignment facilitate flexible installation
Sturdy design ensures stability in windy conditions
Compact and
Lightweight Packaging
Small and lightweight boxes
benefit shipping, logistics and retail.
Pharos Control - Centralized Management System
CPE610 comes equipped with Pharos Control centralized management software, helping users easily manage all devices in their network from a single PC. Functions include device iscovery, status monitoring, firmware upgrading, and network maintenance. An intuitive web-based interface- PharOS - provides an alternative management method, and allows professionals to access more detailed configurations.
- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com.au
- Brand Name
- TP-Link
- Product Type
- Wireless Bridge
- Technical Information
- Wireless LAN Standard
- IEEE 802.11a/n
- Frequency Band
- 5 GHz
- Antenna Gain (Isotropic)
- 23 dBi
- Wireless Transmission Speed
- 300 Mbit/s
- Interfaces/Ports
- Ethernet Technology
- Fast Ethernet
- Number of Network (RJ-45) Ports
- 1
- PoE (RJ-45) Port
- Yes
- Power Description
- Power Consumption
- 8.80 W
- Physical Characteristics
- Height
- 205.7 mm
- Width
- 365.8 mm
- Depth
- 279.4 mm
- Miscellaneous
- Environmentally Friendly
- Yes
