- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com/c/en_au
- Brand Name
- Cisco
- Product Line
- Aironet
- Product Series
- 2700
- Product Type
- Wireless Access Point
The Cisco Aironet 2700 Series of Wi-Fi access points (APs) delivers industry-leading 802.11ac performance at a price point ideal for plugging capacity and coverage gaps in dense indoor environments. The Aironet 2700 Series extends 802.11ac speed and features to a new generation of smartphones, tablets, and high-performance laptops now shipping with the faster, 802.11ac Wi-Fi radios.
The Aironet 2700 series supports 802.11ac "Wave 1" In its first implementation, providing a theoretical connection rate of up to 1.3 Gbps. That's roughly triple the rates offered by today's high-end 802.11n APs. The boost helps you stay ahead of the performance and bandwidth expectations of today's mobile worker, who usually uses multiple Wi-Fi devices instead of just one. As such, users are adding proportionally larger traffic loads to the wireless LAN, which has outpaced Ethernet as the default enterprise access network.
- Warranty
- Limited Warranty
- Lifetime
- Technical Information
- Wireless LAN Standard
- IEEE 802.11ac
- ISM Band
- Yes
- UNII Band
- Yes
- ISM Minimum Frequency
- 2.41 GHz
- ISM Maximum Frequency
- 2.46 GHz
- UNII Minimum Frequency
- 5.18 GHz
- UNII Maximum Frequency
- 5.83 GHz
- Wireless Transmission Speed
- 1.27 Gbit/s
- Wireless Security
- IEEE 802.11i
- WPA2
- WPA
- IEEE 802.1X
- AES
- TKIP
- EAP-TLS
- EAP-TTLS
- MSCHAPv2
- PEAP
- EAP-MSCHAPv2
- EAP-FAST
- PEAP v1
- EAP-GTC
- Features
- MIMO Technology
- Interfaces/Ports
- Ethernet Technology
- Ethernet
- Fast Ethernet
- Gigabit Ethernet
- Number of Network (RJ-45) Ports
- 2
- PoE (RJ-45) Port
- No
- VGA
- No
- HDMI
- No
- Audio Line Out
- No
- Serial Port
- No
- USB
- No
- Powerline
- No
- Management Port
- Yes
- Physical Characteristics
- Form Factor
- Ceiling Mountable
- Height
- 50.5 mm
- Width
- 220.7 mm
- Depth
- 220.7 mm
- Weight (Approximate)
- 997.9 g
- Miscellaneous
- Certifications & Standards
- UL 60950-1
- CAN/CSA-C22.2 No. 60950-1
- UL 2043
- IEC 60950-1
- EN 60950-1
- EN 50155
- FCC Part 15.247, 15.407
- RSS-210 (Canada)
- EN 300.328, EN 301.893 (Europe)
- ARIB-STD 66 (Japan)
- ARIB-STD T71 (Japan)
- EMI and susceptibility (Class B)
- FCC Part 15.107 and 15.109
- ICES-003 (Canada)
- VCCI (Japan)
- EN 301.489-1 and -17 (Europe)
- EN 60601-1-2 EMC requirements for the Medical Directive 93/42/EEC
- 802.3
- 802.3u
- 802.3ab
- 802.11a
- 802.11b
- 802.11g
- 802.11n
- 802.11ac
- 802.3af
- 802.3at
- 802.11h
- 802.11d
